The R package survivalSL contains a variety of functions to construct a super learner in the presence of censored times-to-event and to evaluate its prognostic capacities. Compared to the available packages, we propose additional learners, loss functions for the parameter estimations, and user-friendly functions for evaluating prognostic capacities and predicting survival curves from new observations. We performed simulations to describe the value of our proposal. We also detailed its usage by an application in multiple sclerosis. Because machine learning is increasingly being used in predictive studies with right-censoring, we believe that our solution can be useful for a large community of data analysts, beyond this clinical application .
In clinical practice, the prediction of the probability that a subject will experience an event is often of interest. For instance, for patients with multiple sclerosis under first-line treatment, the prediction of disease progression would result in the early identification of non-responders and help in deciding the switch to second-line treatment. However, the time-to-disease progression is often not observable for all subjects because of a lack of follow-up, i.e., right-censoring.
Several regressions can be used for prediction from right-censored data. The most popular is probably the proportional hazards (PH) model (Cox 1972). The corresponding baseline hazard function can be obtained by assuming parametric distributions (Andersen et al. 1985), nonparametric estimators (Lin 2007) or other flexible approaches such as splines (Rosenberg 1995). Penalized PH models have also been proposed, particularly useful for high-dimensional data (Goeman 2009). The accelerated failure times (AFT) approach also constitutes an alternative to the PH assumption (Wei 1992).
In parallel to these regression-based methods, machine learning is increasingly used. Support-vector machines (Shivaswamy et al. 2007), neural networks (Faraggi and Simon 1995), or even random forests (Ishwaran et al. 2008) have been successfully developed for censored time-to-event data. Ensemble learning allows us to combine regressions and algorithms by minimizing the cross-validated loss function (Breiman 1996). SL was first proposed by van der Laan et al. (2007) and van der Laan and Dudoit (2003) from the theory of unified loss-based estimation.
Polley et al. (2011) and Polley and van der Laan (2011) extended the SL to right-censored data. Two R-based solutions are available on GitHub repositories. The SuperLearner-Survival repository is related to the work by Golmakani and Polley (2020). It allows us to obtain the linear predictor of a PH regression. The survSuperLearner package was developed by Westling (2021) with additional learners: several parametric PH models (Exponential, Weibull, log-logistic, and piecewise constant hazard), generalized additive Cox regression, and random survival forest.
In this paper, we aim to extend these solutions by i) additional learners (accelerated failure times, neural networks, penalized regressions), ii) several loss functions for the estimation of the parameters (Brier score, negative binomial log-likelihood, etc.) and iii) user-friendly S3 methods for evaluating the predictive capacities, as well as predicting survival curves from new observations (Section 1). In the second section, we propose a simulation-based study to compare the performances of our proposal with that of the alternative solutions. In the third section, we detail its usage by an application in multiple sclerosis. Finally, we discuss the strengths, weaknesses and perspectives of our solution.
For a subject \(i\) in a sample of \(N\) independent subjects \((i=1,...,N)\), we denoted the time-to-event by \(T_i^\star\). Right-censoring leads the observation of \(T_i=\min(T_i^\star, C_i)\), where \(C_i\) is the censoring time. Let \(D_i= \mathbb{1}\left \lbrace T_i^\star \leq C_i \right \rbrace\) be the event indicator. The survival function at time \(t\) for a subject with the characteristics \(Z_i\) at baseline is defined by \(S(t \mid Z_i ) = \mathbb{P}(T_i^\star> t \mid Z_i)\).
Let \(S_{sl}(.)\) be the survival function obtained by the SL such as \(S_{sl}(t \mid Z_i)=\sum_{m=1}^M w_m \times S_m(t \mid Z_i)\), where \(S_m(.)\) is the survival function obtained by its \(m\)th learner (\(m = 1,...,M\)), and \(w = (w_1,...,w_M)\) are the corresponding weights with respect to \(\sum_1^M w_m=1\) and \(0 \leq w_m \leq 1\). The estimations of the learners and the weights can be obtained by respecting the following steps (Polley and van der Laan 2010):
Estimate the \(M\) models or algorithms on the entire sample as usual. The procedure of estimation can be different for each model. For instance, a parametric model may be fitted by maximizing the full likelihood, a Cox regression by maximizing the partial likelihood and estimating the baseline survival function with Breslow method, or a random survival forest by maximizing the between-node survival differences according to the log-rank statistic.
By using the \(M\) models or algorithms estimated in the step #1 (\(m=1,...,M\)), predict the values \(\hat{S}_m(u \mid Z_i)\) for each subject \(i=1, ...,N\) and for a vector of \(U\) times (\(u = u_1, ..., u_U\)) and stack the values in a 3-dimensional array of size (\(N\) \(\times\) \(U\) \(\times\) \(M\)).
Split the sample into a training and validation sample according to a V-fold cross-validation, i.e., \(V\)-equal size and randomly selected groups. Let \(T(v)\) be the \(v\)th training sample and \(V(v)\) be the corresponding validation sample (\(v = 1, .., V\)).
For the \(v\)th fold, estimate the \(M\) models or algorithms from \(T(v)\). The learners based on the estimation of hyperparameters should be tuned for each of the \(V\) folds. Note that this tunning step is often based on cross-validation and should be performed for each of the \(V\) folds. Regarding the corresponding computational burden, a compromise consists of using the hyperparameters estimated at the step #1 (Le Borgne et al. 2021).
Compute the corresponding predicted survival rates for the individuals of the validation sample \(V(v)\) and the \(U\) times.
Stack the predictions \(\tilde{S}_m(u \mid Z_i)\) obtained in the step #5 in a 3-dimensional array of size (\(N\) \(\times\) \(U\) \(\times\) \(M\)).
Determine the loss function \(\mathbb{L} (w \mid \tau)\) for quantifying the gap of the predictions \(\tilde{S}_{sl}( \tau \mid Z_i) = \sum_{m=1}^M w_m \tilde{S}_m(\tau \mid Z_i)\) and the observations \((T_i, D_i)\) for a prognostic up to \(\tau\). The loss functions available in the package are listed in the next subsection.
Estimate the weights \(w\) by minimizing the loss function for a prognostic up to a time \(\tau\):
\[\hat{w} = \underset{w}{\mathrm{arg \; min}} \; \mathbb{L} (w \mid \tau)\]
\[\hat{S}_{sl}(t \mid Z_i) = \sum_{m=1}^M \hat{w}_m \hat{S}_m(t \mid Z_i)\]
Several loss functions \(\mathbb{L} (w \mid \tau)\) are available in the package. The Brier score (BS) for right-censored data and a prediction at time \(\tau\) is defined by: \[BS(w \mid \tau) = \frac{1}{N} \sum_{i} \left [ \frac{ \tilde{S}_{sl}( \tau \mid Z_i)^2 \mathbb{1} \lbrace T_i \leq \tau, D_i=1 \rbrace }{ \hat{G}(T_i) } + \frac{ ( 1-\tilde{S}_{sl}( \tau \mid Z_i))^2 \mathbb{1} \lbrace T_i>\tau \rbrace } { \hat{G}(\tau) } \right ]\] where \(\hat{G}(u)=\mathbb{P}(C_i > u)\) is the survival function of the censoring time (Houwelingen et al. 2012). The corresponding \(\tau\)-restricted integrated BS is \(RIBS(w \mid \tau) = \int_0^{\tau} BS(u) du\). The integrated BS equals \(RIBS(w \mid \max(T_i^\star))\). We also considered the negative binomial log-likelihood (BLL), which is defined for a prognostic at time \(\tau\) as follows: \[BLL(w \mid \tau) = \frac{1}{N} \sum_{i} \left[ \frac{ \log (1-\tilde{S}_{sl}( \tau \mid Z_i) ) \mathbb{1} \lbrace T_i \leq \tau,D_i=1 \rbrace } {\hat{G}(T_i)} + \frac{ \log ( \tilde{S}_{sl}( \tau \mid Z_i) ) \mathbb{1} \lbrace T_i>\tau \rbrace } { \hat{G}(\tau) }\right]\] We also proposed the corresponding integrated and \(\tau\)-restricted integrated versions. Additionally, we implemented the concordance index (CI) as defined by Uno et al. (2011): \[CI(w \mid \tau) = \frac{\sum_{i}\sum_{j} \mathbb{1} \lbrace T_j < T_i , \tilde{S}_{sl}( \tau \mid Z_j) > \tilde{S}_{sl}( \tau \mid Z_i) \rbrace D_j}{ \sum_{i}\sum_{j} \mathbb{1} \lbrace T_j < T_i \rbrace D_j }\] Finally, we considered the area under the time-dependent ROC curve, i.e., the sensitivity (SE) against one minus the specificity (SP) at each threshold \(\eta\) (Hung and Chiang 2010):
\[ SE_\eta(w \mid \tau) = \frac{ \sum_i D_i \mathbb{1}\lbrace T_i \leq \tau , \tilde{S}_{sl}( \tau \mid Z_i) > \eta \rbrace / (1 - \hat{G}(T_i)) }{ \sum_i D_i \mathbb{1}\lbrace T_i \leq \tau \rbrace / (1 - \hat{G}(T_i))}\] \[SP_\eta(w \mid \tau) = \frac{ \sum_i \mathbb{1}\lbrace T_i > \tau , \tilde{S}_{sl}( \tau \mid Z_i) \leq \eta \rbrace }{ \sum_i \mathbb{1}\lbrace T_i > \tau \rbrace } \]
Several models or algorithms are proposed in the survivalSL package:
Parametric AFT models. They can be considered with Weibull, Gamma or generalized Gamma distributions (flexsurv package). The parameters are estimated by likelihood maximization.
Parametric PH models. They can be considered with Exponential or Gompertz distributions (flexsurv package). The parameters are estimated by likelihood maximization.
Spline-based PH models. We considered the spline-based survival model proposed by Royston and Parmar (2002). To estimate the baseline distribution, it involves one hyperparameter: the number of internal knots of the natural cubic spline, with a default grid search \(k = \left \lbrace 1, 2, 3, 4 \right \rbrace\). The parameters are estimated by likelihood maximization (flexsurv package).
Semi-parametric PH models. It corresponds to a PH model (coxph function of the survival package) with a non-parametric baseline hazard function estimated by using the Breslow estimator (Lin 2007). This approach can be used with or without a forward selection of covariates by using the AIC.
Penalized PH models. For high-dimensional data and/or covariate selection, three penalties can be used for the previous semiparametric PH model: Lasso, Ridge, or Elastic-Net (glmnet package). The quantitative covariates are transformed with B-splines to relax the log-linear assumption. The hyperparameters \(\lambda\) of the Lasso regression allows for selection of the covariates, while it allows for the shrinkage of the regression coefficients in the Ridge regression. The Elastic-Net allows the two penalties. By default, we implemented the grid search proposed by Simon et al. (2011) for \(\lambda\) and \(\left \lbrace 0.1, 0.2, ..., 0.9 \right \rbrace\) for \(\alpha\). The Lasso penalization corresponds to \(\alpha=0\), while the Ridge penalization corresponds to \(\alpha=1\).
Random survival forests. This ensemble tree method extends Breiman’s random forest framework to right-censored data (Ishwaran et al. 2008). It allows estimation of the cumulative hazard function in each node by using the nonparametric estimator of survival proposed by Aalen (1978). It involves three hyperparameters (randomSRC package): number of covariates to test for splitting the node, minimal number of events per terminal node, and number of trees. The default grid search is mtry = \(\left \lbrace 1,2,...,2+0.5\times \textrm{number of covariates} \right \rbrace\), nodesize \(= \left \lbrace 2, 4, 6, 10, 20, 30, 50, 100 \right \rbrace\) and ntree \(= 500\), respectively.
Survival neural networks. We implemented the method proposed by Biganzoli et al. (1998). It allows using the nnet package for estimating a feed forward neural network model for partial logistic regression. It involves four hyperparameters: the length of the time intervals, the number of units in the hidden layer, the weight decay, the maximum number of iterations, and the maximum allowable number of weights. The optimal combination is estimated by cross-validation and the previous possible loss functions. The default grid search is composed by inter \(= 1\), size \(= \left \lbrace 2, 4, 6, 8, 10 \right \rbrace\), decay \(= \left \lbrace 0.001, 0.01, 0.02, 0.05 \right \rbrace\), maxit \(= 100\), and MaxNWts \(= 10000\), respectively.
We simulated 1000 data sets for each scenario. The times-to-event were generated from Weibull distributions with PH assumption. The censoring times were generated from uniform distributions to obtain a 40% censoring rate. We studied two sample sizes for learning (200 and 500), while the validation samples were composed of 500 subjects. We proposed two contrasting scenarios (Figure ?? in Appendix):
A simple scenario with 6 independent covariates, 2 were continuous and 4 qualitative. Among them, 1 continuous and 2 qualitative covariates were associated with the times-to-event distribution without any log-linearity issue.
A complex scenario with 23 correlated covariates: 12 continuous covariates (several nonlinear relationships, two effects were step functions, two were quadratic functions, five were log-linear), 11 qualitative covariates and 1 interaction.
We compared our proposed SL with each included learner, the perfectly specified PH model (i.e., the model used to generate the times-to-event, the only estimation consisting of the regression coefficients), and the SL obtained by the survSuperLearner package (Westling 2021). We decided to use the package proposed by Westling (2021) as a comparator because it includes additional learners compared to the functions proposed by Golmakani and Polley (2020). The SL weights were estimated by minimizing the integrated BS (IBS) for all the methods.
In the SL proposed by Westling (2021), we included the 5 possible learners: the PH model with the Breslow estimator, the Exponential PH model, the random survival forests, the Lasso PH model and the PH model with the univariate selection of covariates (\(p<0.05\)). We used the default grid of the hyperparameters.
In our proposed SL, we included the 7 possible learners: the PH model with the Breslow estimator, the same model with forward selection based on AIC minimization, the Elastic-Net PH model with B-splines on quantitative covariates, the random survival forest, the Exponential PH model, the Gamma distribution-based AFT model, and the survival neural network. Note that we did not consider the Weibull PH model since it was used for data generation. We used the default grid of the hyperparameters.
Figure 1 presents the distributions of the IBS over the learning (on the left) and validation samples (on the right). The related R code is available in Appendix. Consider the situation where \(N=200\) for learning and \(N=500\) for validation (the first two plots on the top). The perfectly specified model had the lower IBS. This result was expected since it constitutes the gold standard to reach by the other methods. The Elastic-Net PH regression outperformed all the other approaches in the learning samples. This result explained the important weight of this method, approximately 25% in our SL, as illustrated in Figure 5 in Appendix. Nevertheless, this apparent result was not observed in the validation samples, illustrating overfitting.
In both the learning and the validation samples, our proposed SL, the PH model with the Breslow estimator, and the same model with forward selection based on the AIC had the best performances, higher than that of the SL proposed by Westling (2021).
The survival neural network and the PH model with an Exponential distribution were associated with larger values of the IBS in both the learning and the validation samples. Comparatively, the results were closed across the other methods. In the validation samples, the highest variability of the IBS was observed for the survival neural network.
Figure 1: Simulation results in the simple context.
When \(N=500\) in both the learning and the validation samples (the two bottom plots of Figure 1), the results were close. However, one can note that the means and variances of the IBS were lower.
The related R code is available in Appendix. As illustrated in Figure 2, regarding the results in the validation samples, our proposed SL and the Elastic-Net PH regression outperformed the other models/algorithms. More precisely, the mean of the IBS was lower for the Elastic-Net PH model for a learning sample size of 200. The value of our proposed SL was close. When \(N=500\) for learning, the mean of the IBS was lower for our SL, but that of the Elastic-Net PH model was close. Nevertheless, regardless of the sample size for learning, our SL was associated with lower variance in the IBS.
Among the other differences compared to the simple context, the random survival forests and the survival neural networks performed better than the other model-based predictors, except the Elastic-Net PH model.
In both the learning and the validation samples, and regardless the sample size for learning, our proposed SL had slightly higher performances compared to the results of the SL proposed by Westling (2021).
